7i85 encoder inputs and my drives
- Type_Zero_Design
- Offline
- Premium Member
Less
More
- Posts: 133
- Thank you received: 7
31 May 2019 03:31 #135445
by Type_Zero_Design
7i85 encoder inputs and my drives was created by Type_Zero_Design
I'm working on getting my servo encoders hooked up to my 7i85 and I'm just trying to cross the descriptions from the 7i85 instructions and the servo drive instructions. I attached a picture of both side by side.
I'm trying to figgured out which wires from the drive I would hook to where on the 7i85 as the descriptions of the functions between the two are not very consistent
I guess in the end what would connect where from the drive to pins 1-8 on the 7i85.
Thanks!
I'm trying to figgured out which wires from the drive I would hook to where on the 7i85 as the descriptions of the functions between the two are not very consistent
I guess in the end what would connect where from the drive to pins 1-8 on the 7i85.
Thanks!
Attachments:
Please Log in or Create an account to join the conversation.
- Hakan
- Offline
- Platinum Member
Less
More
- Posts: 490
- Thank you received: 155
31 May 2019 05:10 - 31 May 2019 05:13 #135447
by Hakan
Replied by Hakan on topic 7i85 encoder inputs and my drives
QA0 to PAOUT+
/QA0 to PAOUT-
Same for B and Z. Jumpers on 7i85 set to differential input.
/QA0 to PAOUT-
Same for B and Z. Jumpers on 7i85 set to differential input.
Last edit: 31 May 2019 05:13 by Hakan.
Please Log in or Create an account to join the conversation.
- Type_Zero_Design
- Offline
- Premium Member
Less
More
- Posts: 133
- Thank you received: 7
31 May 2019 13:51 #135469
by Type_Zero_Design
Replied by Type_Zero_Design on topic 7i85 encoder inputs and my drives
So that was my thought, but PZOUT doesn't really have a match on the 7i85.
Would I put PZout to IDX0?
Also should the ground and +5v from the 7i85 be hooked up to the drive?
Would I put PZout to IDX0?
Also should the ground and +5v from the 7i85 be hooked up to the drive?
Please Log in or Create an account to join the conversation.
- PCW
- Away
- Moderator
Less
More
- Posts: 17861
- Thank you received: 4775
31 May 2019 14:09 #135471
by PCW
Replied by PCW on topic 7i85 encoder inputs and my drives
Yes Z=Index
No to 5V connection
If the drives encoder ground = frame ground no to ground connection
if the drives encoder ground is floating, connect it to 7I85 encoder ground
No to 5V connection
If the drives encoder ground = frame ground no to ground connection
if the drives encoder ground is floating, connect it to 7I85 encoder ground
