7i77 watch dog catch 22
13 Aug 2024 01:50 #307606
by Benb
7i77 watch dog catch 22 was created by Benb
Question 1:
Is there an output pin for an external Estop/reset safety circuit to read the status of 7i77 WDT? If not, would it be feasible to use one of the existing pin outputs by Keeping this output pin ON while the watchdog timer has NOT bit. Here where the catch 22 comes into play, when the WDT bites, the hostmot2 driver disables the digital outputs therefore my external hardwired circuit will not be able to determine the WDT output pin status (see diagram Highlighted in RED). One way I can think of to solve this puzzle is to restrict the WDT from internally disabling the digital outputs, and have WDT just set a flag and let the hardwired safety circuit take care of disabling the power to the digital outputs. Or I am out to lunch?Question 2:
7i77 field terminal block has several terminals I am hoping to be able to keep the field power OFF to the digital outputs until the safety lockout circuit is reset and the field digital inputs and VIN powered while the ESTOP circuit is active. If you look at the wiring diagram, I need the numbers of the terminal blocks marked with question mark (highlited in green). Nomenclature:
CR# – CONTROL RELAY
MCR - MASTER CONTROL RELAY
F# - FUSE
DI – DIGITAL INPUT
DO – DIGITAL OUTPUT
PB – PUSH BUTTON
WDT – WATCH DOG TIMER
L1 - MAIN SUPPLY LINE 120 VAC
N - MAIN SUPPLY NEUTRAL
PL- Pilot Light A brief explanation to what this hardwired circuit does follows this diagram.
The wiring circuit diagram below is a hardwired circuit that will allow power to be removed from digital outputs, servos and spindle. The circuit achieves the following:
Is there an output pin for an external Estop/reset safety circuit to read the status of 7i77 WDT? If not, would it be feasible to use one of the existing pin outputs by Keeping this output pin ON while the watchdog timer has NOT bit. Here where the catch 22 comes into play, when the WDT bites, the hostmot2 driver disables the digital outputs therefore my external hardwired circuit will not be able to determine the WDT output pin status (see diagram Highlighted in RED). One way I can think of to solve this puzzle is to restrict the WDT from internally disabling the digital outputs, and have WDT just set a flag and let the hardwired safety circuit take care of disabling the power to the digital outputs. Or I am out to lunch?Question 2:
7i77 field terminal block has several terminals I am hoping to be able to keep the field power OFF to the digital outputs until the safety lockout circuit is reset and the field digital inputs and VIN powered while the ESTOP circuit is active. If you look at the wiring diagram, I need the numbers of the terminal blocks marked with question mark (highlited in green). Nomenclature:
CR# – CONTROL RELAY
MCR - MASTER CONTROL RELAY
F# - FUSE
DI – DIGITAL INPUT
DO – DIGITAL OUTPUT
PB – PUSH BUTTON
WDT – WATCH DOG TIMER
L1 - MAIN SUPPLY LINE 120 VAC
N - MAIN SUPPLY NEUTRAL
PL- Pilot Light A brief explanation to what this hardwired circuit does follows this diagram.
The wiring circuit diagram below is a hardwired circuit that will allow power to be removed from digital outputs, servos and spindle. The circuit achieves the following:
- If power is lost during operation the machine will not restart when power is re-established.
- If an Estop is activated or a fault occurs during operation, the circuit will inhibit (prevent) power to digital outputs, servos and spindle. The rest of the machine control circuit will stay in the ON state; this will enable you to troubleshoot and resume operation without major reinitialization of the machine.
- Machine will not restart until all faults are corrected and operator presses reset button.
Attachments:
Please Log in or Create an account to join the conversation.
13 Aug 2024 02:56 #307608
by PCW
Replied by PCW on topic 7i77 watch dog catch 22
A 7I77 watchdog fault occurs when communication with LinuxCNC is lost.
This is not something you typically recover from without restarting
LinuxCNC, that is, it usually means LinuxCNC or the host PC has crashed.
or host communication to the FPGA card has been lost or serial communications
have been lost
This is not something you typically recover from without restarting
LinuxCNC, that is, it usually means LinuxCNC or the host PC has crashed.
or host communication to the FPGA card has been lost or serial communications
have been lost
Please Log in or Create an account to join the conversation.
13 Aug 2024 11:01 #307623
by Benb
Replied by Benb on topic 7i77 watch dog catch 22
Moderator could you please move this message to driver bords section. By mistake I asked the question in the wrong section, my appologies
Please Log in or Create an account to join the conversation.
- tommylight
- Away
- Moderator
Less
More
- Posts: 18726
- Thank you received: 6296
13 Aug 2024 12:29 #307625
by tommylight
Thank you.
Replied by tommylight on topic 7i77 watch dog catch 22
Done.Moderator could you please move this message to driver bords section.
Thank you.
Please Log in or Create an account to join the conversation.
14 Aug 2024 01:50 #307693
by Benb
Replied by Benb on topic 7i77 watch dog catch 22
From PCW response, if any peripheral card such as 7i77 watchdog HAS bit, the main power supply must be turned off.For implementation since 7i77 does not have a dedicated digital output. One way is to dedicate one preferable two of the 7i77 digital outputs to signal to the main power supply circuit to cut the power to the machine. I will update the schematic when I get chance.Good night, folks
Attachments:
Please Log in or Create an account to join the conversation.
15 Aug 2024 00:58 #307759
by Benb
Replied by Benb on topic 7i77 watch dog catch 22
a simplified example of hardwired estop/reset is posted in the hal examples section
